Our projects: Silos

Ash silos in Estonia

Numerical calculations (GMNIA) for two CC3 class steel silos, carried out in co-operation with SBD s.c. by the company Monta Sp. z o.o. in Estonia

• Calculations for CC3 class silos taking into account major thermal actions
• Numerical dimensioning with use of GMNIA method pursuant to EN 1993-1-6
• Determination of the static equilibrium path of the structure along with shell optimisation
• Manual verification of the results of numerical analysis
• Calculations and documentation pursuant to EN in English language

Steel aggregate transfer station in Austria

Executive documentation for steel structure of aggregate transfer station along with connection static analysis

• Gravel container of 50 m3 capacity
• Stone container of 80 m3 capacity with a swing-out horizontal scaffolding
• Supporting structure for all elements including stone crusher
• Working platforms with stairs and handrails
• DIN documentation in German

Barite silos in Venezuela

Static and strength calculations for barite silos mounted on barges

• Numerical dimensioning of silos
• Taking into account the influence of waving and tilting of the structure
• Structure optimisation
• Manual verification of the obtained results
• Calculations pursuant to EN in Polish language

Sand silo - Switzerland

Static calculations and executive documentation of a sand silo

• Static and strength calculations for the silo
• Preparation of working documentation along with sheet metal cut-outs
• DIN-EN documentation in German

Supporting structure for a silo in Germany

Static analysis of connections and working documentation of the supporting structure of the silo and working platforms

• Static analysis for bolted and welded connections
• Working documentation for supporting structure
• Working documentation for working platforms
• DIN-EN documentation and calculations in German

Ash silo in Poland

Static analysis for an ash silo of a capacity of over 2500m3

• Complete MES model of silo with ribs and perimeter rings
• Stress analysis of the whole structure
• Calculations of shell bearing capacity in accordance with PN-EN and of the bearing capacity of vertical ribs in accordance with ECCS
• Construction optimisation
